FROM Mild TO WiLD - We have your mustang fueling needs cover

The most capable fuel system at this price level available. The core kit which the rest are built on. This kit includes:

-Radium Hat w/ Bucket and 2x TI274 Pumps

-High quality micro-relay wiring harness with plug and play connectors wherever possible

-Adapter and gauge to show fuel pressure

Everything you need minus vacuum hose to run to the regulator. We can provide this as well if you discuss how you'd like to run it for your particular setup.

The Stage 2 builds off the Stage 1 with a little bit more flow potential.

Adds:

-Full -8AN braided feed line

- Massive stainless steel E85 safe filter with serviceable element.

Optional:  ($55) Optional billet check valve for easiest starts

For big power we remove the on-hat regulator and go to a conventional external billet regulator and return line.

Adds:

-Black 1:1 adjustable fuel pressure regulator

-Full -8AN feed and -6AN return lines

Optional - ($100) Include fittings and hose required to setup existing rails in a full parallel nature.

($350) Full billet rails and all hose and fittings required for full parallel including a low profile billet 180 as required

($55) Billet check valve for easiest starts

($75) Upgrade from TI274 to TI285 fuel pumps

Have 1400+ HP? Need 3 pumps? This is your kit.

Adds:

-Fore Triple Pump Hat w/ TI274 pumps

-10AN Feed Line w/ -8AN Return Line

-Pressure switch for pump #3 with integrated wiring

-Standard parallel routing for your existing rails

Optional - ($55) Billet check valve for easier starts

($250) Billet rail add-on with parallel routing

($139) Upgrade from TI274 to TI285 fuel pumps

Includes everything you need to upgrade your Stage 1 kit to a full external regulator parallel rail Stage 3 kit.

 -Black 1:1 adjustable fuel pressure regulator

-Full -8AN feed and -6AN return lines

-Configured for rails in parallel for existing rails

Optional: ($250) Billet rail upgrade

($55) Billet check valve for easiest starts

The same premium harness we use in our kits. Can be adapter to any aftermarket fuel system in any vehicle. Made for us by Jn2ning right in Texas.

-GXL wire that meets Ford M1L-85B and SAE J-1128 specs.

-35 amp 280 series micro relays

-Delphi 280 series connections and inline fuse holders

Optional: ($35) Honeywell Plug and Play Hobbs switch

($NO CHARGE) GT500/GT350 hat style connector

($35) Add a relay for triple pumps
